Details
-Compact cargo bike designed to safely carry 2 kids, with plenty of heel clearance for the rider even if the kiddos require child seats
- Powerful Bosch Cargo Line motor provides up to 85 Nm of torque and up to 400% support
- Easy-to-use, intuitive Bosch e-bike system helps you stay informed and in control on the road
- Custom 1 x 9-speed e-bike drivetrain with trigger shifter for faster, more precise shifting
- Built tough for hauling, rated to a maximum gross vehicle weight of 190 kg (419 lb) with a rear rack load capacity of 90 kg (198 lb)
- Robust, patented Atlas Kickstand keeps the bike steady for safe loading & unloading of cargo and passengers
- Create customized setups using our wide range of kid & cargo-carrying accessories
- Adjusts without tools to fit riders 155 - 185 cm (5'1" - 6'1"), weighing up to 120 kg (265 lb)
- Third-party tested for safety & meets benchmark German cargo bike standard DIN 79010, with the frame and fork tested well beyond the requirements
Long-Lasting Support
Tern bikes are built for the long haul, but even the toughest bikes will eventually require some TLC to keep going strong. In addition to a 10-year limited warranty, Tern will have replacement parts available for your Quick Haul Long for a minimum of 7 years from the date of purchase. This is essential, since critical parts like the battery will wear out over time and will need a replacement during the lifetime of your bike.
Specs
Frame | Tern Quick Haul Long, Patented Design, 6061-AL, DIN 79010 certified: 190 kg (419 lb) |
---|---|
Fork | Cargo, Aluminum alloy, DIN 79010 certified: 190 kg (419 lb) |
Electric-Assist Type | Bosch Cargo Line |
Motor Specs | 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
Battery Type/Weight | Bosch PowerPack 500 |
Charger Type | 220V, 4A (EU); 100-240V, 4A (US) |
Range on Full Charge | 500 Wh: 42-85 km (26-53 mi) |
Max. Assisted Speed | 20 mph |
Saddle | Velo Comfort |
Handlebars | Low riser ergo, 31.8, 6061-AL |
Bicycle Drivetrain | Tektro 11-42T, 9 spd |
Wheels | Tern Atlas H, cargo |
Tires | Schwalbe Pick Up, 60-406, Super Defense puncture protection, Reflex |
Brakes | Tektro hydraulic disc |
Weight | 29.3 kg (64.6 lb) |
Color(s) | Satin Traffic Red, Satin Black |
Sizes | One Size |
Accessories & Extras | Aluminum Bell • SKS Chainblade Chainguard • Atlas Kickstand, for cargo • 90 lux, StVZO approved Front Light • Herrmans Rear Light • SplashGuard Fenders • Atlas L, 90 kg (198 lb) capacity Rear Rack • ABUS or AXA, keyed-alike with Bosch battery Frame Lock |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Satin Traffic Red | 12-9-31 | TER43998350Y |
Satin Black | 12-9-30 | TER38663288Y |
